Technical Specs
Basic Block Features
Wire Range (Rated Cross Section):4 mm² (AWG 26 – AWG 10)
UL/CSA Voltage Rating:600V AC/DC
UL/CSA Current Rating:30 A
Width:6.1 mm
Electrical Standards/ Certifications:IEC / UL / CSA / ATEX / IECEx
Color:Grey
Detail Data
Block Type:Feed-Through
Circuit per Block:Single-Circuit
Connection Points:2 Points On One Side, 2 Points On Other Side
Number of Levels:Single Level
Wiring Diagram:1492-P4Q
Wire Range (Rated Cross Section):4 mm² (AWG 26 – AWG 10)
UL/CSA Voltage Rating:600V AC/DC
UL/CSA Current Rating:30 A
Width:6.1 mm
Electrical Standards/ Certifications:IEC / UL / CSA / ATEX / IECEx
Color:Grey
Detail Data
Block Type:Feed-Through
Circuit per Block:Single-Circuit
Connection Points:2 Points On One Side, 2 Points On Other Side
Number of Levels:Single Level
Wiring Diagram:1492-P4Q
