Tecnichal data
| With integrated auxiliary switch | No |
| With integrated under voltage release | No |
| Rated permanent current Iu | 60 A |
| Rated operating voltage | 220 A |
| Type of control element | Other |
| Type of electrical connection of main circuit | Screw connection |
| Rated impulse withstand voltage (Uimp) | 8 kV |
| Rated motor current, max (In) | 60 A |
| Insulation voltage (Ui) | Rated 1000V per IEC |
| Electrical life cycle | 8000 @ 415V AC |
| Adjustable rated motor current | I1 = 0.4…1 x In (24…60 A) |
| Trip class | Class 3E, 5E, 10E, 20E (approx. 2…20 s) |
| Voltage for reverse-fed circuit breaker, max | 480V AC per UL/CSA |
| Rated ultimate short-circuit breaking capacity (Icu) | 70 kA @ 500V DC- 3 poles in series per IEC 60947-2 |
| Rated service short-circuit breaking capacity (Ics) | 100% of Icu @ 690V AC, 50/60 Hz per IEC 60947-2 |
| Interrupting rating | 65 kA @ 480V AC, 50/60 Hz per NEMA, UL 489/CSA C22.2, No. 5 |
| Instantaneous current | Adjustable from 6…13 x In |
| Number of poles | 3 |
| With thermal protection | Yes |
| Phase failure sensitive | Yes |
| Switch off technique | Thermomagnetic |
| Control element | Toggle |
| Interrupting rating/breaking capacity | High break |
| Unbalace detection | 50% of I1, ON or OFF |
| Width | 90 mm |
| Depth | 82.5 mm |
| Height | 130 mm |
| Frame size | 125 A |
| Device construction | Built-in device fixed built-in technique |
| Degree of protection (IP) | IP20 |
| Mechanical life operations | 25000 /h |
| Protection type | Thermal/magnetic- adjustable thermal/fixed magnetic TMD |
| Factory option | 1 NO/NC auxiliary + 1 alarm 24V AC/DC |
| Weight, approx | 2.6 lb |
| Wire temperature rating | Cu 75 ðC |
| Operating temperature | -13 ðF |
| Storage temperature | -40 ðF |
| Ambient temperature without derating | 104 ðF [40 ðC] |
